MR-J20B Servo driver
MITSUBISHI MR-J20B Manual And Instructions
MR-J20B datasheetPDF datasheet
MR-J20B Specifications and Instructions Manual
MITSUBISHI MR-J20B Product information and technical parameters：
Brand: MITSUBISHI
Name: Servo driver
Model: MR-J20B
Type: MR-J_B series.
Rated output: 0.2KW.
Interface: standard.
Servo system according to the system structure can be divided into open loop servo system, closed loop servo system, semi closed loop system, compound control system.
The closed loop automatic control system with feedback is composed of a position detecting part, a deviation amplifying part, an executing part and a controlled object.
Servo system must have good controllability, high stability and high adaptability.
Note that the control of the signal is good after the disappearance of the signal, can immediately stop the turn;
High stability is the torque with the increase of speed and uniform decline; adaptability is fast, sensitive, and ring state quality is good.
According to the types of servo drives are classified, there are three kinds of electric, hydraulic or electric hydraulic.
If the servo system is divided according to the function, then there is a measuring servo and power servo system;
Analog servo and power servo system; position servo and acceleration servo system.
The electric servo system can be divided into two categories: DC DC servo system and AC AC servo system based on the electrical signals.
AC AC servo system also has two kinds of asynchronous motor servo system and synchronous motor servo system.
