HG-KR73J Low inertia small capacity servo motor
MITSUBISHI HG-KR73J Manual And Instructions
HG-KR73J datasheetPDF datasheet
MITSUBISHI HG-KR73J Product information and technical parameters：
Brand: MITSUBISHI
Name: Low inertia small capacity servo motor
Model: HG-KR73J
Servo motor series: low inertia, small capacity.
Rated output: 0.75kw.
Rated speed: 3000r/min.
Electromagnetic brake: No.
Oil seal: incidental (Note 1, note 2, note 3).
Power supply: 200V.
Note 1 through HG-KR and HG-MR series 0.1kW and HG-SR series can be supported.
Note 2 with the speed reducer case, do not configure the oil seal.
Note 3 with oil seal HG-KR, HG-MR series servo motor''s appearance size standard is different.
The rated speed is 3000r/min, the maximum speed is 6000r/min.
The maximum torque of 350% of the rated torque, high torque in the field of high rotation, only to support the HG-KR series products.
Built in absolute position encoder with high resolution.
Standard high resolution absolute position encoder (4194304p/rev (22bit)).
To achieve a higher accuracy of the positioning function.
Improve the environmental performance of HG-KR, HG-MR, HG-RR, HG-UR series of products using IP65.
