FX3G-60MT/ESS PLC
MITSUBISHI FX3G-60MT/ESS Manual And Instructions
FX3G-60MT/ESS datasheetPDF datasheet
FX3G-60MT/ESS HARDWARE MANUAL
FX3G-60MT/ESS Hardware EditionUSER'S MANUAL
FX3G-60MT/ESS Positioning Control EditionUSER'S MANUAL
FX3G-60MT/ESS Basic & Applied Instructions EditionPROGRAMMING MANUAL
FX3G-60MT/ESS MODBUS Serial Communication EditionUSER'S MANUAL
MITSUBISHI FX3G-60MT/ESS Product information and technical parameters：
Brand: MITSUBISHI
Name: PLC
Model: FX3G-60MT/ESS
Input points: 36 points.
Output points: 24 points.
Power supply voltage: AC240-360V.
Output type: transistor output (drain).
A free combination of PLC.
FX3G basic unit: 14/24/40/60 point.
FX3GA is a compact PLC, simple design and with the basic functions of the FX3 series.
Through the strengthening of the built-in function and flexible expansion, expanded in various fields of application.
Third generation standard model.
High flexibility.
Suitable for small scale control of high cost.
Control points to 128 points, the use of CC-Link remote I/O can control the maximum 256 points.
High speed operation.
Basic instructions: 0.21 s/ instruction.
Application instruction: 0.5 s/ instruction.
Large capacity memory.
Built in program memory 32000 steps.
EEPROM memory cartridge with program transfer function.
