For GOT multipoint connection.
Applicable models: GT15, GT16, GT11, GT10, GT27, GT25, GT23, GT21. "Series introduction: with a variety of advanced features of the compact model.
Screen size: 5.7 inches.
Display color: 256 color or more color.
Mounting type: panel mounting type.
Resolution: QVGA (320 x 240) A9GT-FNB4M.
Display device: STN color.
Host frame color: black.
Power type: DC24V.
Communication interface: with built-in RS-422 A9GT-FNB4M
The first characteristic of touch screen:
Transparent, it directly affects the visual effect of touch screen.
The problem of transparency is the degree of transparency, infrared technology, touch screen and surface acoustic wave touch screen is separated by a layer of pure glass,
Transparency can be considered a leader, the other touch screen this is a good scrutiny, transparency",
The touch screen industry, is a very broad concept, many touch screen is a multilayer composite film,
It''s not enough to generalize its visual effect with only a little transparency,
It should include at least four characteristics: transparency, color distortion, reflection and clarity, but also,
For example, the degree of reflection, including the degree of specular reflection and diffraction,
But the touch screen surface diffraction reflection has not reached the extent of the CD disk,
For users, these four metrics are basically enough A9GT-FNB4M A9GT-FNB4M. "Protective film for 5.7 inch screen.
Transparent (frame: white), 5.
Applicable model: GT14. Function: high performance and low price in the middle end model.
Picture size: 8.4 inches.
Resolution: SVGA.
Display: TFT color.
Panel color: black.
Power type: DC24V.
Communication interface: CC-Link IE network communication module set.
The highest level model with multi touch and gesture features.
Specification rich, design at ease.
GT27 standard supports SD memory card and standard equipped with Ethernet, RS-232, RS-422/485, host/device USB interface.
Even in the log, script, alarm, soft component data transmission, such as high load processing period, but also to achieve smooth operation of the screen.
In addition, also supports video, animation playback, video input and RGB input and output, can use all the features of GOT2000.
Can be programmed CPU and other procedures, parameters, such as data storage (backup) to the SD GOT memory card, USB memory.
When the programmable controller fails, batch write back (recovery) program.
1, the human body sensor
People will be able to automatically detect and display the picture.
2, USB interface: device USB (Mini-B USB)
Can connect to the computer to transfer data.
3, USB interface: host USB (USB-A)
GOT data can be transmitted through the USB memory or read log data and other data,
Can also be connected to the USB mouse, keyboard use.
4, the extension of the interface
Communication module aand optional module can be installed A9GT-FNB4M.
5, Ethernet interface
Up to 4 different manufacturers can be connected to the FA machine.
6, RS-232 interface
Can connect all kinds of FA machine, bar code reader, serial printer.
7, RS-422/485 interfface
Can be connected to a variety of FA machines, bar code reader A9GT-FNB4M.
8, SD memory card slot
Can save alarm and log data, such as a large number of data.
