Servo motor series: low inertia, medium and large capacity.
Rated output: 8.0kw.
Rated speed; 1000r/min.
Electromagnetic brake: incidental.
Power supply: 400V.
Most suitable for medium and large capacity, low inertia type products in high frequency operation or acceleration and deceleration operation.
Improve the environmental performance of HG-SR, HG-JR series of products using IP67.
High speed & high torque Q6BAT Shorten the positioning time, achieve high-speed equipment.
100 scene, there are 100 different drive control.
In order to meet the needs of the diverse and detailed field,
MR-J4 product line configuration, providing a wealth of servo amplifier and servo motor products.
Can meet the different needs of different customers. Cable length 3 meters.
Extended substrate for connection.Drive: MR-H_AN series.
Rated output: 0.1KW.
Universal AC servo.
Servo driver (drives servo) also known as the "servo controller", "servo amplifier",
Is a kind of controller used to control the servo motor. Its function is similar to that of the frequency converter,
Belongs to a part of the servo system, which is mainly used in high precision positioning system.
In general, the servo motor is controlled by position, speed and torque in three ways,
To achieve high precision positioning of the transmission system, the current transmission technology is the high-end products.
Servo drive is an important part of modern motion control,
Is widely used in industrial robots and CNC machining centers and other automation equipment.
In particular, it has become a hot research topic in the field of servo drives for the control of AC permanent magnet synchronous motor.
Current, speed and position 3 closed loop control algorithm based on vector control is widely used in AC servo drive system.
The speed closed-loop design of the algorithm is reasonable or not, for the entire servo control system,
Especially the speed control performance plays a key role.Motor series: medium inertia, medium capacity.
Using a serial absolute / incremental encoder.
Rated output power: 0.5kw.
Rated speed: 2000rpm.
With a brake band.
Shaft end: straight shaft.
The rotor of AC servo motor is usually made of squirrel cage, but in order to make the servo motor has a wide range of speed regulation, linear mechanical properties,
Without the "rotation" phenomenon and the performance of the fast response, it is compared with the ordinary motor,
The two characteristics of rotor resistance and moment of inertia should be provided.
At present, there are two kinds of rotor structure, one is the squirrel cage rotor, which is made of conductive material with high resistivity,
In order to reduce the moment of inertia of the rotor, the rotor is slender.
Q6BAT Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=Q6BAT&select=5
