Operation control mode: stored procedure repeated operation.
Built in IE CC-Link.
Input / output points: 4096 points.
Program capacity: 320K.
Program capacity of up to 1200K.
Multi CPU system for high precision motion control.
The built-in CPU module support 2 Gigabit Network port.
Database functions to facilitate data management.
Extended SRAM card with built-in security function.
Can be carried out a variety of motion control (position, speed, torque, advanced synchronous control, etc MR-J3-100B).
In line with the international safety standards (13849-1 PL e ISO, IEC 61508 SIL 3) security CPU.
The most suitable for C/C++ language programming from the computer / computer environment for transplantation.
Standard interface.
The programmable controller CPU module has standard Ethernet port, USB port, SD card slot.
Ethernet port and USB port can be used to communicate with the corresponding peripheral devices,
SD memory card slot can be used to record data, databases and other data storage.
In addition, the expansion of the SRAM card can be used for the expansion of the capacity of the soft element / tag memory and used as a hardware security key. MITSUBISHI inverter series: FR-A800.
Voltage level: three phase 400V.
Power: 37kw.
SLD converter rated current: 93A.
Structure and function: Standard model.
Type: CA.
Substrate coating: have.
Mirror like ultra fine processing.
In order to adapt to the new material diversification, the machine adopts the most cutting-edge technology, more than ever more slim hard.
In order to be able to realize the fine cutting, grinding on the hard and hard material,
The need for high-speed operation has become more and more strong.
In order to cope with the increasing demand of logistics, every port in the world has a crane in every day.
A container filled with cargo.
We can achieve a new type of inverter products under the conditions of low speed and high torque to achieve smooth cargo handling operations,
Carry on the smooth movement to the heavy. Series introduction: with a variety of integrated functions and communication interface, and a larger volume of the basic model.
Screen size: 8.4 inches.
Display color: 256 color or more color.
Mounting type: panel mounting type.
Resolution: VGA (640 x 480).
Display device: TFT color.
Host frame color: black.
Power type: DC24V.
Communication interface: with built-in RS-422.
With a variety of integrated functions and communication interface and a larger volume of the basic model.
User storage capacity: 6MB.
Device USB interface.
Standard Ethernet, RS-422/485 and RS-232 interface.
Analog touch panel.
From the technical principle to distinguish the touch screen, can be divided into five basic types: vector pressure sensor touch screen, resistive touch screen, capacitive touch screen technology, infrared touch screen technology, surface acoustic wave touch screen technology.
Vector pressure sensing technology touch screen has been withdrawn from the stage of history;
Infrared touch screen technology and low price, but the frame is fragile, easy to produce light interference and surface distortion;
The design of capacitive touch screen is reasonable, but it is difficult to solve the problem of image distortion;
The touch screen positioning resistor technology is accurate, but its price is high, and fear of vulnerability scratch;
The surface acoustic wave touch screen solves various defects of the touch screen in the past,
Clear and not easy to be damaged, suitable for various occasions,
The disadvantage is that the screen surface if there is water droplets and dust will make the touch screen become slow, or even work.
MR-J3-100B Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=MR-J3-100B&select=5
