MITSUBISHI motor universal AC servo amplifier MELSERVO-J3W series (a two axis servo amplifier).
Rated output A axis: 1.0kw.
Rated output B axis: 1.0kw.
Interface type: SSCNET type III fiber communication.
With the same high performance, multi functionality and practicality of the MR-J3-B servo amplifier,
Each MR-J3W-B servo amplifier can be used to rotate the servo motor,
Combined control of any two kinds of linear servo motor and direct drive servo motor HC-MFS13BG1
The installation area can be reduced by 25% to 17% compared with two MR-J3-B servo amplifiers.
Therefore, a more compact control system can be constructed.
In addition, the two axes use the same main circuit power supply, control circuit power supply and SSCNET III communication fiber, thus greatly reducing the wiring.Type: HA-SH series.
Rated output: 1.5KW.
Rated speed: 2000r/min.
Electromagnetic brake: there.
From the vector control technology of AC servo motor, it has become more and more popular.
From the point of view of the real time operating system, it is just a function module that needs to be processed in real time.
Due to the multi function of the controller, intelligent requirements, a large number of signal processing,
Establishment and operation of various mathematical models of adaptive control,
Network communications and other functional modules will be in the real-time operation of the unified scheduling and management of the system to get the correct and reliable operation.
Therefore, the next generation of servo drive controller will be a collection of various modern control technology of the crystallization,
Instead of the traditional sense of power amplifier.Available network: 10BASE2.
Max / total distance: 185/925m.
A1SJ71E71 is a compact Ethernet interface module,
Used to hang PLC series ANS to ethernet.
There are two kinds of hanging network modules: A1SJ71E71-B2-S3 and A1SJ71E71-B5-S3 respectively corresponding to 10BASE2 and 10BASE5,
So that the vast majority of installed cable can continue to use.
HC-MFS13BG1 Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=HC-MFS13BG1&select=5
