Type: HA-ME series.
Rated output: 0.75KW.
Rated speed: 3000r/min.
Electromagnetic brake: there.
Control complex, easy to achieve intelligent,
The electronic commutation method is flexible and can be changed by square wave or sine wave.
Motor maintenance free, high efficiency, low operating temperature,
Electromagnetic radiation is very small, long life, can be used in a variety of environments.
AC servo motor is brushless motor, which is divided into synchronous and asynchronous motor,
Synchronous machines are commonly used in motion control,
Its power range, you can do a lot of power GT16-70PSGB
Large inertia, the maximum rotation speed is low, and with the increase of power and rapid reduction.
So it is suitable for the application of low speed and stable operation.
The rotor of the servo motor is permanent magnet,
Drive controlled U/V/W three phase electric electromagnetic field,
The rotor rotates under the action of the magnetic field,
At the same time the motor comes with the encoder feedback signal to the drive,
According to the feedback value and the target value, the driver is compared,
Adjust the rotor rotation angle.
The accuracy of the servo motor is determined by the accuracy of the encoder. 1 axis servo amplifier.
MITSUBISHI general AC servo amplifier MELSERVO-J4 series.
Rated output: 12.0kw.
Interface: General purpose.
Power supply: three phase AC200V.
Servo amplifier supporting universal interface.
Servo amplifier for universal interface.
Speed / torque control of position control and analog voltage command can be carried out by using pulse train command.
Support Max instruction pulse frequency 4 Mpulses/s.
The industry''s top level speed motor, the frequency of 2.5kHz amplifier, and optical fiber network extradimensional Symphony orchestra.
Using the traditional two degree of freedom model adaptive control to further optimize the exclusive high speed servo control structure of the dedicated execution engine.
Achieved the fastest 2.5kHz speed frequency response in the industry.
Combined with MITSUBISHI independent research and development of high resolution absolute position encoder (4194304pulses/rev),
Greatly improve the processing speed. Can maximize the performance of high-end machinery.
GT16-70PSGB Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=GT16-70PSGB&select=5
