Analog input points: 4 points (PT1000/Nil000).
Resolution: 0.1 degrees.
Weight: 0.1kg.
Dimensions: 17.6 x 90 x 89.5.
FX3U-4AD-PNK-ADP is a PT1000/Nil000 temperature sensor with analog input adapter.
Thermocouple (K type, J type) and PT1000/Nil000 temperature sensor with analog input adapter.
-100~1000 degree can be measured by 4 channels.
No programming to send data to FX3 series.
Connect FX3SA, FX3S, FX3GA, FX3G, FX3U,
Need to convert adapter or function extension board FX3U-64MT/ESS Specification: allowed regeneration power: 300W, resistance value: 40 ohm.
Uses: MR-JE-70B, MR-JE-100B, MR-JE-70A, MR-JE-100A with. CC-Link (intelligent equipment station).
Twisted pair. Input type: DC input, positive public end / negative public end.
Input points: 16 points.
Enter the response time: 0.2ms below, below 1.5ms, 5ms below, 10ms the following.
Rated input voltage / current: DC24V/7mA.
External connection: 3 wire.
According to the external connection mode and the external equipment input and output specifications,
Choose from a rich product lineup.
Finger protection through the upper part of the terminal,
The human body will not be exposed to live parts,
Therefore, the terminal station type remote I/O module can be directly mounted to the machine tool. MITSUBISHI motor universal AC servo amplifier MELSERVO-J3 series.
Rated output: 0.75kw.
Interface type: SSCNET type III fiber communication.
Special specification: suitable for linear servo motor.
Power specification: single phase AC200V.
More advanced real-time automatic tuning by setting response values,
Including the position gain and the gain of speed, all the gain can be adjusted automatically.
32 segment response level can be set.
Advanced vibration suppression control.
An optimal vibration control filter value is automatically set by the automatic tuning function to effectively suppress the vibration of the 100Hz frequency that occurs when the driving part stops.
The automatic tuning function can effectively restrain the vibration of the end of the mechanical arm and reduce the residual vibration in the machine.
FX3U-64MT/ESS Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=FX3U-64MT/ESS&select=5
