Motor series: low inertia, medium capacity.
Rated output power: 30.0kw.
Rated speed: 1500rpm.
With the brake: without.
Shaft end: straight shaft.
The rotor of the servo motor is a permanent magnet, which is controlled by the U/V/W,
The rotor rotates under the action of the magnetic field, and the encoder feedback signal of the motor is given to the driver,
According to the feedback value and the target value, the driver adjusts the rotation angle of the rotor FX3U-64CCL
Accuracy of the servo motor depends on the accuracy of the encoder (number of lines). MITSUBISHI motor universal AC servo amplifier MELSERVO-J3 series.
Rated output: 1.0kw.
Interface type: SSCNET type III fiber communication.
Special specification: suitable for direct drive servo motor.
Power specification: three phase AC200V.
Direct drive system suitable for high speed and high precision!
High speed operation can be realized by direct drive (2m/s), and the traditional mechanical transmission can not achieve such a high speed.
The full closed loop control can be realized by using the position feedback signal from the load side encoder, such as the linear encoder.
The use of a flexible linear servo motor drive components can make the system more compact structure.
The primary side of the linear servo motor (motor coil) is sliding along the secondary side (permanent magnet) of the motor,
So linear servo motor is especially suitable for large range of applications. In addition, linear servo motor can be connected in series,
Especially for large systems in two axes for high precision synchronous operation. Input points: 32 points.
Output points: 32 points.
Output form: transistor.
Connected programmable logic controller: FX1NC, FX2NC, FX3UC.
FX2NC expansion module can be directly connected to the FX1NC, FX2NC, PLC FX3UC on the expansion of the input and output.
Do not need to connect the cable and so on, therefore can carry on the compact expansion. Input / output points: 4096 points.
Number of input and output elements: 8192.
Program capacity: 100 K step.
Processing speed: 0.0095 s.
Program memory capacity: 400 KB.
Support USB and RS232.
Support installed memory card.
Providing high speed communication between multiple CPU.
High speed and high precision data processing.
The processing speed of the real number (floating point) arithmetic has been greatly improved,
Addition instruction reached 0.014 mu s,
Therefore, it can support the request of high-speed, high-precision processing data processing.
In addition, the new addition of double precision floating point arithmetic instructions,
Simplify the programming, reduces the computational error when executing complex formula.
Shorten the fixed scan interrupt time, high precision device.
The minimum interval of the fixed period interrupt program is reduced to 100 s.
The high speed signal can be accurately obtained, which makes the contribution to the higher precision of the device.
FX3U-64CCL Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=FX3U-64CCL&select=5
