PC-9800 computer (half pitch 14 pin)Maximum frequency: 50kHz.
Input points: 1 points.
Output form: transistor 2 point output.
Weight: 0.13kg.
FX2NC-1HC can achieve high speed counting by 1 phase /2 phase 50kHz hardware counter.
Hardware comparator with high speed matching output function.
In the 2 phase count, can be set 1, 2, 4 frequency.
Can be achieved by PLC or external input to count the licensing / prohibition AY23C
Can also be connected to the linear drive output type of the encoder.
FX2NC-1HC can only be connected to FX3UC. Function: CPU module (internal service power supply).
Input and output points: 64 points.
Power supply capacity (DC5V power): 1100mA.
Power supply capacity (DC24V service power supply): 600mA.
Input / output mode: DC input (drain / source) / transistor (drain).
Input points: 32 points.
Output points: 32 points.
The new expansion module is more convenient!
Pioneer products with advanced built-in functions and rich extensibility.
FX5U built-in analog, communication, high speed input and output,
By extending the board and adapter can be easily extended system.
In addition, through the high speed system bus,
Can maximize the role of the built-in intelligent functions of the expansion device.
RS-485 communication. Special communication adapter.Self service (IN, OUT): SI optical cable.
Other aspects (IN, OUT): SI optical cable.
Data link anomaly Bureau bypass.
Inter agency extension.
Cable transformation. MITSUBISHI general purpose AC servo amplifier MR-J2 series.
Rated output: 3.5kw.
Interface: general purpose interface.
Voltage: three phase AC200V.
MITSUBISHI servo system in the MITSUBISHI servo amplifier is widely used,
It can not only be used in the high precision position control and speed control of the working machinery and general industrial machinery,
Can also be used in the field of speed control and tension control.
By installing a personal computer with a servo setting software, the parameters setting, trial run, state display, and gain adjustment are performed.
MITSUBISHI servo system MR-J2S column is developed on the basis of the servo MR-J2 series with a higher performance and more features of the MITSUBISHI servo system,
The control modes are position control, speed control and torque control, as well as the switching control mode among them.
AY23C Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=AY23C&select=5
