"MITSUBISHI inverter series: FR-A846.
Voltage level: three phase 400V.
Power: 15kw.
SLD converter rated current: 38.0A.
Structure and function: IP55 counterpart.
Type: CA.
Substrate coating: have.
Built in DC reactor.
Easy to operate, simple settings.
We have prepared a series of equipment and functions for you to work in any place to meet the life cycle of the product.
Allegedly, the motor power consumption accounted for about half of the total power generated by manufacturing industry consumption HC-RF203B
How to achieve energy efficiency in the plant without affecting the productivity.
Less energy consumption and more output FR-A800 series inverter will help you to have both fish and bear''s paw"
Parameters and frequency settings can be modified in the program.
Inverter control, for example, by the input signal to trigger the operation of the inverter, based on the operation of the inverter
The status of the signal output, as well as the monitor output and so on, can be customized according to the requirements.
The control of each machine can be done separately by the frequency converter, and the control of the dispersion is also carried out.
Through combining with the real-time clock function can realize the automatic operation (in option FR-LU08). "Features: high cost of second models.
Picture size: 10.4 inches.
Resolution: VGA.
Display: TFT color.
Panel color: black.
Power type: DC24V.
Specification rich, design at ease
GT23 standard supports SD memory card and standard equipped with Ethernet, RS-232, RS-422/485, host/device USB interface.
Support log, one to many connections, FA transparent transmission and other diverse FA machine related functions.
System configuration diagram shows in order to form the connection with the GOT programmable controller system,
Easily confirm module status. In addition, after touching each module,
Can start its corresponding expansion function, to facilitate system maintenance, shorten the time of failure.
1, simple design
In order to cope with the use of a variety of scenarios, to abandon all the nonsense of the decoration, the use of straight tone of the minimalist design.
2, plane body
Surface mining pure plane design, easy to clean. (USB interface at the back)
3, Ethernet interface
Up to 2 different manufacturers can be connected to the FA machine.
4, RS-232 interface
Can connect all kinds of FA machine, bar code reader, serial printer.
5, RS-422/485 interface
Can be connected to a variety of FA machines, bar code reader.
6, USB interface: device USB (Mini-B USB)
Can connect to the computer to transfer data.
7, USB interface: host USB (USB-A)
USB data can be transmitted through the USB memory or read log data, such as the GOT data, but also can be connected to the use of the mouse, keyboard.
8, SD memory card slot
Can save alarm and log data, such as a large number of data.
Can be collected through the GOT programmable controller, temperature regulator and other data, and to chart, list display.
Computer analysis can also be used to save the data. Even in the case of a power outage, the log data can be saved to the built-in SRAM.
HC-RF203B Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=HC-RF203B&select=5
